Date Log
Analisa Spesifikasi Fluff, Pellet, dan Bricket Pelepah Kelapa Sawit sebagai Biomassa Co-firing untuk Pembangkit Listrik
Corresponding Author(s) : Ari Aditia Sukma Sukma
Journal of Bioprocess, Chemical and Environmental Engineering Science,
Vol 4 No 1 (2023): Journal of Bioprocess, Chemical, and Environmental Engineering
Abstract
The abundance of palm frond waste in Indonesia makes it an ideal source as co-firing material to increase renewable energy consumption. Therefore, it is necessary to determine whether oil palm fronds in the form of fluff, pellets, and brickets can be used as co-firing fuel. This study also aims to see whether there are differences in the potential of hard and soft palm fronds as solid fuel for power plants, as well as to calculate its slagging and fouling risk. Palm fronds was dried and reduced in sized using a wood chipper then sifted with a 20 mesh sieve to obtain palm frond fluff, then the fluff was mixed with 22% tapioca adhesive (weight ratio of 20% of the biomass) to be molded into pellet. Meanwhile, wood brickets was prepared by pyrolyzing the hard fronds (T= 550oC, t= 5 min) and mixing the charcoal obtained with 22% tapioca adhesive (weight ratio of 30% of the biomass). From the results of the analysis carried out, it is known that palm frond bricket provides the best results with an NCV value of 7095 cal/g. On the other side, both hard frond fluff and soft frond fluff contains the same sulfur content (0.06%), thus the difference in using hard or soft fronds as co-firing fuel does not have much effect. Furthermore, based on the analysis of potential slagging and fouling, all types of oil palm frond samples studied are shown to have a low to medium risk level.
Keywords
Download Citation
Endnote/Zotero/Mendeley (RIS)BibTeX
References
Akogun, O., & Waheed, A. (2019). Property Upgrades of Some Raw Nigerian Biomass through Torrefaction Pre-Treatment- A Review. Journal of Physics: Conference Series. 1378, 1-14.
Amri, I., Muchlis, T., & Helwani, Z. (2021). Upgrading karakteristik biopelet tandan kosong sawit dengan penambahan oil sludge sebagai co-firing. Journal of Bioprocess, Chemical, and Environmental Engineering Science. 1, 1-11.
Babcock, G.H., & Wilcox, S. (2005). Steam: Its Generation and Use. Ohio: McDermott Company.
Basu, P. (2018). Biomass Gasification, Pyrolysis and Torrefication (2nd Ed). New York: Elsevier Inc.
Bonsu, B. O., Takase, M., & Mantey, J. (2020). Preparation of charcoal briquette from palm kernel shells: Case study in Ghana. Heliyon. 6, 1-8.
Darmansyah, Anhar, K., Muhammad, K., & Teguh, S. (2021). Pengaruh ukuran serbuk dan kekerasan kayu terhadap kualitas syngas dari pirolisis biomassa. Jurnal Syntax Admiration. 2(4), 592-600.
Dey, I., Irwan, S., & Hengky, A. (2016). Pemanfaatan biomassa serbuk gergaji sebagai penyerap logam timbal. Jurnal Akademika Kimia. 5(4), 166-171.
Duan, L., Duan, Y., Zhao, C., & Anthony, E. J. (2015). NO emission during co-firing coal and biomass in an oxy-fuel circulating fluidized bed combustor. Fuel. 150, 8–13.
Hariana, Fairuz, M. K., Dani, R., & Lan, M. T. N. (2020). Investigation on slagging fouling potential in coal blending for PLTU with PC boiler with droptube furnace method. Kresna Social Science and Humanities Research. 1, 28-40.
Hassan, S., Kee, L. S., & Al-Kayiem, H. H. (2013). Experimental study of palm oil mill effluent and palm oil frond waste mixture as an alternative biomass fuel. Journal of Engineering Science and Technology. 8(6), 703-712.
Jeong, T. Y., Sh, L., Kim, J. H., Lee, B. H., & Jeon, C. H. (2019). Experimental investigation of ash deposit behavior during co-combustion of bituminous coal with wood pellets and empty fruit bunches. Energies. 12(11), 1-17.
Koppejan, J., & Loo, S. V. (2008). The Handbook of Biomass Combustion and Co-firing. London: Earthscan.
Kumar, R. M. D., & Anand, R. (2019). Production of biofuel from biomass downdraft gasification and its applications. Advanced Biofuels. 129-151.
Lachman, M., Balas, M., Lisy, M., Lisa, H., Milcak, P., & Elbi, P. (2021). An overview of slagging and fouling indicators and their applicability biomass fuels. Fuel Processing Technology. 217, 1-10.
Lahijani, P., & Zainal, Z. A. (2011). Gasification of palm empty fruit bunch in a bubbling fluidized bed: A performance and agglomeration study. Bioresource Technology. 102(2), 2068–2076.
Maryono, M., Sudding, S., & Rahmawati, R. (2013). Pembuatan dan analisis mutu briket arang tempurung kelapa ditinjau dari kadar kanji. Jurnal Chemica. 14(1), 74-83.
Nunes, L. J. R., Matias, J. C. D. O., & Catalão, J. P. D. S. (2017). Torrefaction of Biomass for Energy Applications. Amsterdam: Academic Press.
Qurotullaili, Q., Komalasari, K., & Helwani, Z. Bahan bakar padat dari pelepah sawit menggunakan proses karbonisasi dengan variasi ukuran bahan baku dan suhu. JOM FTEKNIK. 4(1), 1-5.
Retno, D., Joko, P., & Novia, L. (2017). Studi pengaruh ukuran partikel dan penambahan perekat tapioka terhadap karakteristik biopelet dari kulit coklat (Theobroma Cacao L.) sebagai bahan bakar alternatif terbarukan. Jurnal Teknotan. 11(1), 51-60.
Samuel F. O., Otegbayo, B. O., & Alalade, T. (2012). Nutrient and anti-nutrient content of soy-enriched tapioca. Food Nutr Sci. 3(6), 784-789.
Santosa, S., & Soemarno. (2014). Peningkatan nilai kalor produk pada produk proses bio-drying sampah organik. Indonesian Green Technology Journal. 3(1), 29-37.
Saputra, D., Siregar, A. L., & Rahardja, I. B. (2021). Karakteristik briket pelepah kelapa sawit menggunakan metode pirolisis dengan perekat telung tapioka. Jurnal Asiimetrik: Jurnal Ilmiah Rekayasa dan Inovasi. 3(2), 143-156.
Shaker, B., & Fenjan, R. (2023). Charactrazation of bio-char produced from sesbania stems (sesbania grandiflora). Journal of Engineering and Sustainable Development. 27(2), 204-212.
Sulaiman, S. A., Balamohan, S., Moni, M. N. Z., Atnaw, S. M., & Mohamed, A. O. (2015). Feasibility study of gasification of palm oil fronds. Journal of Mechanical and Sciences. 9, 1744-1757.
Sunaryo, S., Laia, M., & Hakim, L. (2018). Karakteristik bahan bakar pellet biomassa campuran pelepah kelapa sawit dan getah pohon pulai yang diaplikasikan pada kompor biomassa. TURBO. 7(2), 147–152.
Tambaria, T. N., & Serli, B. F. Y. (2019). Kajian analisis proksimat pada briket batubara dan briket biomassa. Jurnal Geosains dan Teknologi. 2(2), 77-86.
Werkelin J., Skrifvars, B.-J., Zevenhoven, M., Holmbom, B., & Hupa, M. (2010). Chemical forms of ash-forming elements in woody biomass fuels. Fuel. 89, 481-493.
Winegartner, E.C. (1974). Coal Fouling and Slagging Parameters. USA: The American Society of Mechanical Engineers.
Yudhistira, P., Zuchra, H., & Komalasari, K. (2017). Pembuatan briket pelepah sawit menggunakan proses torefaksi pada variasi tekanan dan penambahan perekat tapioka. JOM FTEKNIK. 4(1), 1-6.
Zahari, M. W., Alimon, A.R., & Wong, H.K. (2012). Utilization of oil palm co-products as feeds for livestock in malaysia. Biofuel Co-products as Livestock Feed-Opportunities and Challenges. 13, 243-262.
Zhang, S., Hu. B, Zhang. L, & Xiong, Y. (2016). Effects of torrefaction on yield and quality of pyrolysis char and its application on preparation of activated carbon. Journal of Analytical and Applied Pyrolysis. 119(25), 217-223.
